Contant Wattage Heating Cables

TXLP

I-Cable   I-cable underfloor heating cable is designed for new buildings applications or any other circumstances where screed is going to be laid. I-cable is a twin conductor heating cable for easy installation with zero EMF. I-cable underfloor heating cable used for in screed heating for new buildings and suitable for use for all kind of rooms and all kinds of coverings. This systemis usually installed on topof alayer of insulation beneath a50-70mmscreedand the outputcan bevaried when being installed to accommodate your specific circumstance.

HRDVT   The HRDVT-cable is an electrically heated cable designed to prevent snow and ice accumulation around the home or facility, such as driveway, walkways and stairs and so on. In winter, when the accumulated snow on walkways, parking garage, loading ramps, stairways and other areas, it wll bring prob-lem to people' s life. Electric snow melting systems can keep walkways, parking garage, loading ramps, stairways and other areas free of snow and ice to help prevent slip hazards. Electric snow melting systems provide surface snow melting and anti-icing for concrete surfaces and pavement. HRDVT cable also can be used to heat floor, It's a good choice with reliable & strong structure.

UT-Mat     UT-Mat underfloor heating mat uses a twin conductor heating cable for easy installation and mat with zero EMF, designed for instal­lation into thin adhesive beds, leveling compounds or thin screed beds beneath tiled and wooden floor finish.

S-Cable     S-Cable underfloor heating cable is designed to be as thin as possible and 100% screened.The cable is designed for installation into thin adhesive beds, leveling compounds or thin screed beds beneath tile and wooden floor finish.

T-Cable（EU/North America）   T-cable underfloor heating cable is designed to be as thin as possible, diameter only 3.6mm, have two difrent wattage, ensure the economic and energy saving and decrease the floor level to the maximum extent. Designed for installation under tile,woodfloor, marble floor, usually set installation 100W/m²,150W/m² and 200W/m².

UT-Cable   UT-Cable underfloor heating mat uses a twin conductor heating cable for easy installation and mat with zero EMF, designed for instal­lation into thin adhesive beds, leveling compounds or thin screed beds beneath tiled and wooden floor finish.

F-Mat     F-mat underfloor heating mats consist of a twin conductor heating cable with fluoropolymer insulation, and embed in a reinforced aluminum foil mat.The mat total thickness is ultra-thin,decreasing the floor height and increasing the comfort level. F-mat underfloor heating mats are designed for wooden floor, laminated floor and under carpet heating systems. F-mat underfloor heating mats can be cut and turned to achieve the required floor coverage and multiple mats can be joined together to cover large areas.When fiting underfloor heating, a suitable insulation should always be used (especially over con-crete sub floors). 8ow/m² and 15ow/m² mats are provided for option. The 15ow/m² electric heating system can be used as a primary heat source,just for floor warming.

S-Mat     S-mat underfloor heating cable is designed to be as thin as possible and 1oo% screened.The cable is designed for installation into thin adhesive beds, leveling compounds or thin screed beds beneath tile and wooden floor finish. 100w/m² underfloor heating cable provides a highly economical floor warming system and is used to cover larger areas. 10ow/m² is not suitable as a primary heating source, only to be used as secondary heating for under tiled floors. 150w/m² underfloor heating cable is suitable as a primary heating source providing you have adequate insulation. These are our most commonly used mats for kitchens, dining rooms, large bathrooms and most other areas with tiled floors.

T-Mat (EU/North America)     T-mat underfloor heating mat uses a twin conductor heating cable for easy installation and mat with zero EMF, designed for instal­lation into thin adhesive beds, leveling compounds or thin screed beds beneath tiled and wooden floor finish.   150w/m² underfloor heating mats are suitable as a primary heating source providing you have adequate insulation. These are our most commonly used mats for kitchens, dining rooms, large bathrooms and most other areas with tiled floors.  200w/m² underfloor heating mats are generally used in areas where high heat loss is a problem, such as conservatories. These mats are only suitable under tiled floors, giving a 25% faster warm up time.

HRVP(North America)

HRVC (North America)
