Warmfloor Heating cable Undertile heating

Home Products Products Contant Wattage Heating Cables

Warmfloor Heating cable Undertile heating

Warmfloor Heating cable Undertile heating

HRVC (North America)



Inquiry now

NA

Features:





  • Zero EMF
  • Quick and easy installation.
  • Can be used safely in wet conditions like bathroom.
  • Round-shape structure, flexible installation.



  • 15-year warranty
  • About 3.6mm diameter, convenient for installation.
  • Durable structure, long service life requiring no maintenance.
  • Twin conductor structure easy installation.





Technical Data





  • Rated voltage                                                      120V, 240V
  • Power output                                                       3.65W/ft
  • Min. installation temperature                               5°C



  • Applicable areas                                    North America
  • Applications                                           Residential floor warming
  • Min. bending radius                               6D







Catalog Number Length(m) Length(ft) Heating area(11W/ft²) Heating area(14.5W/ft²) Watts(3.65W/ft) Amps Ohms
HRVC-60-1 5.05 16.5 5.5 4.1 60 0.5 240
HRVC-120-1 10.1 33 10.9 8.3 120 1 120
HRVC-180-1 15.1 49.5 16.4 12.4 180 1.5 80
HRVC-240-1 20.1 66 21.8 16.6 240 2 60
HRVC-300-1 25.1 82.5 27.3 20.7 300 2.5 48
HRVC-360-1 30.2 99 32.7 24.8 360 3 40
HRVC-420-1 35.2 115.5 38.2 29 420 3.5 34.3
HRVC-480-1 40.2 132 43.6 33.1 480 4 30
HRVC-540-1 45.3 148.5 49.1 37.2 540 4.5 26.7
HRVC-600-1 50.3 165 54.5 41.4 600 5 24
HRVC-720-1 60.4 198 65.5 49.7 720 6 20
HRVC-840-1 70.4 231 76.4 57.9 840 7 17.1
HRVC-960-1 80.5 264 87.3 66.2 960 8 15
HRVC-1080-1 90.5 297 98.2 74.5 1080 9 13.3
HRVC-1200-1 100.5 330 109.1 82.8 1200 10 12
HRVC-1320-1 110.6 363 120 91 1320 11 10.9
HRVC-1440-1 120.7 396 130.9 99.3 1440 12 10
HRVC-1560-1 130.8 429 141.8 107.6 1560 13 9.2
HRVC-1680-1 140.8 462 152.7 115.9 1680 14 8.6
HRVC-1800-1 150.9 495 163.6 124.1 1800 15 8





Catalog Number Length(m) Length(ft) Heating area(11W/ft²) Heating area(14.5W/ft²) Watts(3.65W/ft) Amps Ohms
HRVC-120-2 10.1 33 10.9 8.3 120 0.5 480
HRVC-180-2 15.1 49.5 16.4 12.4 180 0.8 320
HRVC-240-2 20.2 66 21.8 16.6 240 1 240
HRVC-300-2 25.1 82.5 27.3 20.7 300 1.3 192
HRVC-360-2 30.2 99 32.7 24.8 360 1.5 160
HRVC-420-2 35.2 115.5 38.2 29 420 1.8 137.1
HRVC-480-2 40.2 132 43.6 33.1 480 2 120
HRVC-540-2 45.3 148.5 49.1 37.2 540 2.3 106.7
HRVC-600-2 50.2 165 54.5 41.4 600 2.5 96
HRVC-720-2 60.4 198 65.5 49.7 720 3 80
HRVC-840-2 70.4 231 76.4 57.9 840 3.5 68.6
HRVC-960-2 80.4 264 87.3 66.2 960 4 60
HRVC-1080-2 90.6 297 98.2 74.5 1080 4.5 53.3
HRVC-1200-2 100.6 330 109.1 82.8 1200 5 48
HRVC-1280-2 110.8 363 116.4 88.3 1280 5.3 45
HRVC-1440-2 120.8 396 130.9 99.3 1440 6 40
HRVC-1560-2 130.6 429 141.8 107.6 1560 6.5 36.9
HRVC-1680-2 140.8 462 152.7 115.9 1680 7 34.3
HRVC-1920-2 161 528 174.5 132.4 1920 8 30
HRVC-2160-2 181 594 196.4 149 2160 9 26.7
HRVC-2400-2 201 660 218.2 165.5 2400 10 24
HRVC-2640-2 221.2 726 240 182.1 2640 11 21.8
HRVC-2880-2 241.4 792 261.8 198.6 2880 12 20
HRVC-3120-2 261.6 858 283.6 215.2 3120 13 18.5
HRVC-3360-2 281.6 924 305.5 231.7 3360 14 17.1
HRVC-3600-2 301.8 990 327.3 248.3 3600 15 16
