Brand:
HuanruiPower Ouput:
3.65W/ftMin. Installation Temperature:
5°CRated Voltage:
120V,240VApplicable areas :
EuropeApplication:
Residential floor warmingMin.bending radius:
6DCold lead:
2 wire 18/16AWG + ground braid, 10ft (3.0m) length
Product advantages
1.Durable and strong structure
2.High water-proofness. IP68
3.Long working life
4.25years warranty
5.Small size ,no increase in floor thickness
6.100% screened with Zero EMF
7.100% tested before delivery
8.Free of maintenance
Features and applications:
• Round-shape structure, flexible installation.
• About 3.6 mm diameter, convenient for installation.
• Twin conductor structure with one end cold lead for easy installation.
• Zero EMF.
• Can be used safely in wet conditions like bathroom.
• Quick and easy installation.
• Durable structure, long service life requiring no maintenance.
• 15-year warranty for quality only, not including wrong installation and misuse.
Warranty: 15 years limited warranty against defect in material, design and workmanship.
|
120V |
Length |
Heating area |
Total Power/W (3.65W/ft) |
Current/Amps |
Resistance Ω/m |
||
|
Part Number |
m |
ft |
11W/ft² |
14.5W/ft² |
|||
|
HRVC-60-1 |
5.05 |
16.5 |
5.5 |
4.1 |
60 |
0.5 |
240.0 |
|
HRVC-120-1 |
10.1 |
33.0 |
10.9 |
8.3 |
120 |
1.0 |
120.0 |
|
HRVC-180-1 |
15.1 |
49.5 |
16.4 |
12.4 |
180 |
1.5 |
80.0 |
|
HRVC-240-1 |
20.1 |
66.0 |
21.8 |
16.6 |
240 |
2.0 |
60.0 |
|
HRVC-300-1 |
25.1 |
82.5 |
27.3 |
20.7 |
300 |
2.5 |
48.0 |
|
HRVC-360-1 |
30.2 |
99.0 |
32.7 |
24.8 |
360 |
3.0 |
40.0 |
|
HRVC-420-1 |
35.2 |
115.5 |
38.2 |
29.0 |
420 |
3.5 |
34.3 |
|
HRVC-480-1 |
40.2 |
132.0 |
43.6 |
33.1 |
480 |
4.0 |
30.0 |
|
HRVC-540-1 |
45.3 |
148.5 |
49.1 |
37.2 |
540 |
4.5 |
26.7 |
|
HRVC-600-1 |
50.3 |
165.0 |
54.5 |
41.4 |
600 |
5.0 |
24.0 |
|
HRVC-720-1 |
60.4 |
198.0 |
65.5 |
49.7 |
720 |
6.0 |
20.0 |
|
HRVC-840-1 |
70.4 |
231.0 |
76.4 |
57.9 |
840 |
7.0 |
17.1 |
|
HRVC-960-1 |
80.5 |
264.0 |
87.3 |
66.2 |
960 |
8.0 |
15.0 |
|
HRVC-1080-1 |
90.5 |
297.0 |
98.2 |
74.5 |
1080 |
9.0 |
13.3 |
|
HRVC-1200-1 |
100.5 |
330.0 |
109.1 |
82.8 |
1200 |
10.0 |
12.0 |
|
HRVC-1320-1 |
110.6 |
363.0 |
120.0 |
91.0 |
1320 |
11.0 |
10.9 |
|
HRVC-1440-1 |
120.7 |
396.0 |
130.9 |
99.3 |
1440 |
12.0 |
10.0 |
|
HRVC-1560-1 |
130.8 |
429.0 |
141.8 |
107.6 |
1560 |
13.0 |
9.2 |
|
HRVC-1680-1 |
140.8 |
462.0 |
152.7 |
115.9 |
1680 |
14.0 |
8.6 |
|
HRVC-1800-1 |
150.9 |
495.0 |
163.6 |
124.1 |
1800 |
15.0 |
8.0 |
|
240V |
Length |
Heating area |
Total Power/W (3.65W/ft) |
Current/Amps |
Resistance Ω/m |
||
|
Part Number |
m |
ft |
11W/ft² |
14.5W/ft² |
|||
|
HRVC-120-2 |
10.1 |
33.0 |
10.9 |
8.3 |
120 |
0.5 |
480.0 |
|
HRVC-180-2 |
15.1 |
49.5 |
16.4 |
12.4 |
180 |
0.8 |
320.0 |
|
HRVC-240-2 |
20.2 |
66.0 |
21.8 |
16.6 |
240 |
1.0 |
240.0 |
|
HRVC-300-2 |
25.1 |
82.5 |
27.3 |
20.7 |
300 |
1.3 |
192.0 |
|
HRVC-360-2 |
30.2 |
99.0 |
32.7 |
24.8 |
360 |
1.5 |
160.0 |
|
HRVC-420-2 |
35.2 |
115.5 |
38.2 |
29.0 |
420 |
1.8 |
137.1 |
|
HRVC-480-2 |
40.2 |
132.0 |
43.6 |
33.1 |
480 |
2.0 |
120.0 |
|
HRVC-540-2 |
45.3 |
148.5 |
49.1 |
37.2 |
540 |
2.3 |
106.7 |
|
HRVC-600-2 |
50.2 |
165.0 |
54.5 |
41.4 |
600 |
2.5 |
96.0 |
|
HRVC-720-2 |
60.4 |
198.0 |
65.5 |
49.7 |
720 |
3.0 |
80.0 |
|
HRVC-840-2 |
70.4 |
231.0 |
76.4 |
57.9 |
840 |
3.5 |
68.6 |
|
HRVC-960-2 |
80.4 |
264.0 |
87.3 |
66.2 |
960 |
4.0 |
60.0 |
|
HRVC-1080-2 |
90.6 |
297.0 |
98.2 |
74.5 |
1080 |
4.5 |
53.3 |
|
HRVC-1200-2 |
100.6 |
330.0 |
109.1 |
82.8 |
1200 |
5.0 |
48.0 |
|
HRVC-1280-2 |
110.8 |
363.0 |
116.4 |
88.3 |
1280 |
5.3 |
45.0 |
|
HRVC-1440-2 |
120.8 |
396.0 |
130.9 |
99.3 |
1440 |
6.0 |
40.0 |
|
HRVC-1560-2 |
130.6 |
429.0 |
141.8 |
107.6 |
1560 |
6.5 |
36.9 |
|
HRVC-1680-2 |
140.8 |
462.0 |
152.7 |
115.9 |
1680 |
7.0 |
34.3 |
|
HRVC-1920-2 |
161.0 |
528.0 |
174.5 |
132.4 |
1920 |
8.0 |
30.0 |
|
HRVC-2160-2 |
181 |
594 |
196.4 |
149.0 |
2160 |
9.0 |
26.7 |
|
HRVC-2400-2 |
201 |
660 |
218.2 |
165.5 |
2400 |
10.0 |
24.0 |
|
HRVC-2640-2 |
221.2 |
726 |
240.0 |
182.1 |
2640 |
11.0 |
21.8 |
|
HRVC-2880-2 |
241.4 |
792 |
261.8 |
198.6 |
2880 |
12.0 |
20.0 |
|
HRVC-3120-2 |
261.6 |
858 |
283.6 |
215.2 |
3120 |
13.0 |
18.5 |
|
HRVC-3360-2 |
281.6 |
924 |
305.5 |
231.7 |
3360 |
14.0 |
17.1 |
|
HRVC-3600-2 |
301.8 |
990 |
327.3 |
248.3 |
3600 |
15.0 |
16.0 |
Herein, 1 and 2 means the operation voltage, “1”=120V, “2”=240V
