MSR
MSR is ideally used for process temperature maintenance and frost protection of small diameter pipelines, tanks, valves, flanges. It is suitable for non-hazardous area, and cable with fluoropolymer outer jacket can also be used in hazardous area and corrosive area. What's more, the MSR with fluoropolymer outer jacket can be used inside the water pipe. The material has safety certificate for drinking water; it's safe and made to comply with the environ mental protection standards.
MSR Series
MSR-P: Tinned copper braid provides additional mechanical and ground protection.
MSR-PF: Fluoropolymer outer jacket is used for exposure to organic or corrosive working conditions.
MSR-PB: Flame retardant thermoplastic outer jacket protects against certain inorganic chemical solutions, it also protects against abrasion and impact damage.
Feature
|
|
|
Technical data
|
|
|
| MSR Series | Output power @+10°C (W/m) | Maximum maintain temperature (°C) | Max length @+10°C 16/25A (m) | Max length @0°C 16/25A (m) | Max length @-20°C 16/25A (m) | Dimension (mm) | Weight (kg/100m) |
| 10MSR-PB | 10 | 65 | 60/80 | 54/70 | 40/60 | 8.3x5.4 | 6.6 |
| 10MSR-PF | 10 | 65 | 60/80 | 54/70 | 40/60 | 8.0x5.1 | 6 |
| 15MSR-PB | 15 | 65 | 57/76 | 51/68 | 38/55 | 8.3x5.4 | 6.6 |
| 15MSR-PF | 15 | 65 | 57/76 | 51/68 | 38/55 | 8.0x5.1 | 6 |
| 25MSR-PB | 25 | 65 | 46/55 | 38/50 | 33/49 | 8.3x5.4 | 6.6 |
| 25MSR-PF | 25 | 65 | 46/55 | 38/50 | 33/49 | 8.0x5.1 | 6 |
| 30MSR-PB | 30 | 65 | 37/45 | 35/43 | 30/39 | 8.3x5.4 | 6.6 |
| 30MSR-PF | 30 | 65 | 37/45 | 35/43 | 30/39 | 8.0x5.1 | 6 |
